INSTRUCTIONS

Step 1: Turn the flare die with bushing into the tool head exposing the die about 1/2 inch below.

Step 2: With the die bushing in place, turn the flare shaft all the way up. Lower the die over the case with no contact made with the die.

Step 3: Turn the flare shaft down until you start to feel contact against the neck of the case.

Step 4: Raise the ram and turn the die down until you feel the pressure of the flare shaft against the case.

Step 5: Flare should be .005 under bullet diameter. If you want more flare, raise the ram and continue to turn the die down. Inside diameter measurements should be taken.

Step 6: Lock the die into place.
